IMAGING MULTI–SPECTRAL RADIOMETERS (VIS/IR)
Description
Visible/IR imaging multi-spectral radiometers are used to image the Earth’s atmosphere and surface, providing accurate spectral information at spatial resolutions of order 100m up to several km, with a swath width generally in the range several hundred to a few thousand km.

In addition, these observations can be used to study critical components of the water cycle, such as cloud macro- and micro-physical properties, from which information on atmospheric dynamics and pollutants can be determined.

The information obtained from these instruments is often complemented by that from atmospheric sounders, since atmospheric effects such as absorption must be taken into account in deriving parameters such as surface temperatures.

Recent developments include improvements in spatial resolution (which, in some cases, is equivalent to those of high resolution imagers), spectral resolution, radiometric accuracy and multi-angle capability. Planned hyperspectral instruments that will be able to simultaneously acquire imagery in many tens of wavebands should significantly improve the quality of land cover and land use information derived from satellite imagery.

Applications
Measurements from these multi-spectral radiometers operating in IR and visible bands may be used to infer a wide range of parameters, including sea and land surface temperatures, snow and sea ice cover, and Earth’s surface albedo. These instruments may also make measurements of cloud cover and cloud top temperatures. Measurements of the motion vectors of clouds made by radiometers on geostationary satellites may be used in order to derive tropospheric wind estimates. Accurate information on atmospheric dynamics, derived from the instruments mounted on geostationary meteorological satellites like GMS, GOES or Meteosat, is essential for precise short- and medium-term weather forecasts provided by NWP centres in Japan, the U.S. and Europe.

Visible/IR radiometers are an important source of data on processes in the biosphere, providing information on global vegetation and its variations on subseasonal scales. This allows monitoring of natural, anthropogenic, and climate-induced effects on land ecosystems. Observations by AVHRR on NOAA and MetOp are traditionally used to provide classification and seasonal monitoring of global vegetation types, allowing estimation of primary production (the growth of vegetation that is the base of the food chain) and terrestrial carbon balances. Such information is of great value in supporting the identification of drought areas and provides early warning of food shortages.

Current and planned Instruments
AATSR MS
ABI MS
Advanced KMSS MS
Advanced MI MS (GISTDA)
Advanced MSU-MR MSI (EarthCARE)
ALISEO MSS
AVHRR/3 MSU-GS
AWFI MSU-MR
AWiFS Multi-spectral thermal infrared imager (HyspIRI)
CCD camera MUX
CHRIS MVIRI
EPIC MVIRS
ETM+ MVISR (10 channels)
FCI MX (RS-1A)-VNIR
HRMX MxT
HRMX-TIR NigeriaSat Medium Resolution
HRMX-VNIR NIRST
HSC OLCI
HSTC OLI
HYC OLS
Hyperion PAN (RS-1A)-MX
HySI (IMS-1) Panchromatic High Sensitivity Camera
HySI (RS-1A)-SWIR PCWMP
HySI (RS-1A)-VNIR PSA
HySI-SWIR RASAT VIS Multispectral
HySI-VNIR RASAT VIS Panchromatic
IIR RDSA
Imager SEVIRI
Imager (INSAT) SGLI
IMAGER/MTSAT-2 SLSTR
IR Correlation Radiometer (GeoCape) Sumbandila Sat Imager
IRS TANSO-CAI
IVISSR (FY-2) TIR (OCEANSAT-3/3A)
JAMI/MTSAT-1R TIRS
KMSS TM
LEISA AC UV/Vis Near IR Wide Imaging Spectrometer (Geo-Cape)
MCSI VEGETATION
MERIS VHRR
MERSI VIIRS
MERSI-2 VIRR
METimage VIRS
MI Visible imaging spectrometer (HyspIRI)
MIRS VSC
MMRS WFC
MOC WFI-2
MODIS WS LISS III
A geostationary satellite composite cloud map. Data from these satellites are an essential input to today’s weather forecasting systems.
This spectacular ‘blue marble’ image, produced in early 2002 using data from MODIS, is the most detailed true-colour image of the entire Earth to date.
Further Information
AVHRR: eros.usgs.gov/products/satellite/avhrr.html
SEVIRI (Meteosat): www.eumetsat.int/Home/Main/What_We_Do/Satellites/Meteosat_Second_Generation/index.htm?l=en
IMAGER (GOES): noaasis.noaa.gov/NOAASIS/ml/imager.html
MODIS: modis.gsfc.nasa.gov
VEGETATION: vegetation.cnes.fr
